***traded locally For a PC-10 dedicated***

Bar/Lounge/Waiting room market, it's woodgrain vinyl look is a bit of a throwback to 80s cabaret cabs. The idea is that the cab would blend into areas that were not traditionally locations for arcades.
The "Goldie" as the Neo-Geo crowd dubbed it, is one of the rarest MVS cabs. The MV-2-13 (the tiny one) is probably the only cab that is more rare.
This cab was in terrible condition and has been restored to fully functional condition, and cosmetically excellent. I'm writing a full restore thread, so I'll just bullet here:
  • PCB repaired trace to backup ram, recharging circuit and battery removed, replaced with 2032 socketed coin cell. Unibios 4.0 installed
  • K7000a rebuilt with APaR cap kit and problem areas reflowed when needed. Tube swap with late 2000s RCA (Orion) tube. Old tube had bad burn and guns were really weak. New tube is looking great!
  • Torn down with major repair to the left control panel corner (totally missing). Security door and bar holes dowel filled. I don't believe in forming large areas from bondo, so this is a total cut out and replacement with new material.
  • Black inner areas re-sprayed.
  • Full laminate applied with WilsonArt "Nepal Teak"
  • NOS beston imperial (happ) power supply
  • Control panel, corner protectors stripped down to bare metal, primed and painted.
  • Credit counters rebuilt with new 7 digit displays (originals were scratched up)
  • New Joysticks, all buttons cleaned and switches replaced when needed.
  • New Tmolding
  • New CPO; this was a concession to cost; this is a vinyl reproduction. It does the job, however if you would rather have a Szabo CPO instead, it is NOT glued to the the control panel so it will come right off if you remove the buttons and bolts.
  • Reproduction marquees
  • New fabricated monitor bezel
  • EL Panels are rebuilt with new "bulbs" nice and bright.
Here is some nit-picky things for the OCD people:
A local youth group claimed this cab as their property, so there is a light marking on the glass to indicate that.
Missing serial/model number stickers
someone wrote "good" on the metal top of the PCB. I played with the idea of painting it gold, but I didn't want to go too custom
CPO makes the credit displays a bit fuzzy (original uses plastic window)
Top glass retention bracket is a plastic replacement as the original was missing. Doesn't really make a difference, just full disclosure.
i'm including bust a move and world heroes 2. The bust a move cart is a boot, but i've used it for years with no issues. I only am not using because I have a legit one now.
I've tried to cover everything done, but I may have missed something, so please ask questions if you want. I originally intended a trade, but I've had some unexpected bills crop up so I'm leaning on a cash sale.
Possible trades:
Red Tent
PC10 or VS cab
4 Player Konami cab
Other offers considered.
I have a lot of cash and about 100 hours of work into this one, so I think a fair ask is 2k.


Attachments

  • 1298166C-E353-468F-80DB-210A90410077.jpeg
    1.7 MB · Views: 41
  • 855FD093-1D46-42EF-97A1-DA89E7B9B070.jpeg
    1.9 MB · Views: 41
  • 4E5C6F94-197B-420B-B0A6-2BEECB4ECC27.jpeg
    1.9 MB · Views: 43
  • E1830552-42C4-4A86-ADAE-51E54AB26514.jpeg
    1.8 MB · Views: 39
  • 27907B53-2A91-403C-BA81-6610AA1C71A4.jpeg
    1.8 MB · Views: 36
  • CC71BCA3-BEE1-413B-9E4F-24A93A4886ED.jpeg
    1.7 MB · Views: 37
  • 3C894E69-A76A-42C1-8470-1936829DAD65.jpeg
    1.9 MB · Views: 37
Last edited:

DuffCon

Kuroko's Training Dummy
Rating - 0%
0   0   0
Joined
May 9, 2015
Posts
71
Original condition


Attachments

  • A952341B-FE23-489E-AF96-7D2E139D30FB.jpeg
    1.5 MB · Views: 13

Neo Alec

Orochi Spam Riot
20 Year Member
Rating - 100%
15   0   0
Joined
Dec 7, 2000
Posts
9,843
FMdzkVqWQAEZivv


DuffCon

Kuroko's Training Dummy
Rating - 0%
0   0   0
Joined
May 9, 2015
Posts
71
Apparently it doesn’t perform well under “for sale” conditions tho 😆


Neo Alec

Orochi Spam Riot
20 Year Member
Rating - 100%
15   0   0
Joined
Dec 7, 2000
Posts
9,843
It looks like a very nice system. I'm not sure if the market is willing to support a price that reflects the equity that goes into restoring these.

It's a niche item that requires local pickup, so it may take patience to sell. Luckily you're in SF, so there should be a healthy enough local market. I'd put it on Facebook Marketplace if you haven't already.


DuffCon

Kuroko's Training Dummy
Rating - 0%
0   0   0
Joined
May 9, 2015
Posts
71
Indeed, I don’t expect it to go quickly. You have to have a neo fan who likes Goldies and is local. I knew it coming into it. I’m not crying if I have to house it for a while ;)


heihachi

Host for Orochi
Rating - 100%
15   0   0
Joined
Jul 11, 2016
Posts
753
Great looking machine. I’ve got a Neo cab on my wish list for some time in the next few years, hopefully I’ll be able to find something as nice. Good luck with the sale.


wyo

The Cable Guy
10 Year Member
Rating - 100%
340   0   0
Joined
May 22, 2013
Posts
8,164
Yeah nice work on the restoration. Could be the best looking goldie in existance. As Neo Alec mentioned, there's not a huge market for these but it might be worth 1-2k to the right buyer. Most people are probably looking for a big red. The goldie deserves more love.


Finch

Hardened Shock Trooper
10 Year Member
Rating - 100%
15   0   0
Joined
Jul 14, 2009
Posts
431
They have one of these running at the Santa Cruz Boardwalk, such a cool cab to see in person. Good luck with the sale.
